U-shape drinking straw machine

U-shape drinking straw machineDESCRIPTIONThe series of U-shape tetra pack flexible drinking strawmachine can bend bendable drink straws into U shape and automatically pack them into bags.The complete machine is composed of a driving motor, thin film rolling device(2 groups), a driven system, an unloading device, a straw filling device, a sealing device, a restoring substandard products device and others.The machine boasts easy operation and reliable quality. It is mainly used as the auxiliary equipment for sterile packed drinks such as box.CHARACTERISTICSPacking of U-shape single straws and the completion of bending, filling and packing of straws at a timeAutomatic counting and batch alarmAdjustable packing speedSPECIFICATIONSDriving motor1.5kwcontrol by frequency converterProduction capacity500 700(pcs/min)Packing methodFour sides sealingSpecifications of srtawWrapping materialBoppMaterials that can be hot sealed such as BOPPShapeRoll shapedRoll diametermaximum 280mmInternal diameter of paper tubes76mmWidth of filmmaximum 180mmThickness of film20μ-30μPacking shape22mm(p× 100 140mm(wNormalInside diameterØ 3.8mm Ø 4.8mmStraw wall thickness <, /FONT>0.19-0.25mmLength of U-shape model90mm(small type)\105mm(middle type)128mm(big type)Other specifications are Customizable.Machine size (L×W×H)3000 × 1800 × 1600mm, Machine weight1100kg
